Log Configuration

Applicable to SCEPman Certificate Master version 2.4 and above

Log configuration

Newer SCEPman installations (version 2.4 and later) automatically create a Log Analytics Workspace during deployment and log into Azure Monitor. If you have installed SCEPman 2.3 or earlier and then upgraded to 2.4 or later, you can follow the steps below to enable this logging feature.

Enable Logging to Azure Monitor

The default retention period for data stored in a Log Analytics Table is 30 days. In case a different retention period is required, adjust the configuration of the Table "SCEPman_CL" accordingly.

1. Create a Log Analytics workspace (Microsoft Guide Create a Log Analytics workspace). You can also use an existing one.

2. Add the settings AppConfig:LoggingConfig:WorkspaceId and AppConfig:LoggingConfig:SharedKey described in the section on Logging settings. Do this for each of your SCEPman instances (these are more than one for geo-redundancy or if you have multiple deployment slots) and your Certificate Master App Service.

KQL Query Examples

See Issues with Your SCEPman Instance

SCEPman_CL
| where Level == "Warn" or Level == "Error" or Level == "Fatal"

Number of Issued Certificates by Endpoint in the Selected Time Frame

This query is guaranteed to work with SCEPman 2.8 and future versions. Changes to SCEPman that make this query unusable will be considered Breaking Changes.

SCEPman_CL
| where Level == "Info" and Message startswith_cs "Issued a certificate with serial number"
| project Message, RequestBase = trim_end('/', replace_string(replace_regex(RequestUrl_s, "(/pkiclient\\.exe)?(\\?operation=PKIOperation(&message=.+)?)?", ""),"certsrv/mscep/mscep.dll","intune"))
| summarize IssuanceCount = count() by Endpoint = extract("/([a-zA-Z]+)$", 1, RequestBase)

Starting with SCEPman 2.8, there is always exactly one Info level log entry whose log message starts with "Issued a certificate with serial number " per issued certificate, followed by its serial number. However, due to the unsolvable Two Armies Problem, it can happen that the created certificate never reaches the requester or some other type of error prevents the actual enrollment. Likewise, in case of severe errors, it can happen that a log entry exists without corresponding database entry or vice versa.

Distinct Certificates with OCSP Check

let map_certtype = datatable(serial_start:string, readable:string)
[
  "40", "Intune Device",
  "41", "Intune Device",
  "42", "Intune Incompliant Device",
  "50", "Static",
  "51", "Static",
  "60", "Intune User",
  "61", "Intune User",
  "64", "Jamf User",
  "65", "Jamf User",
  "6C", "Jamf User on Device",
  "6D", "Jamf User on Device",
  "70", "Domain Controller",
  "7C", "Jamf User on Computer",
  "7D", "Jamf User on Computer",
  "54", "Jamf Computer",
  "55", "Jamf Computer",
  "44", "Jamf Device",
  "45", "Jamf Device"
];
SCEPman_CL
| where LogCategory_s == "Scepman.Server.Controllers.OcspController" and Level == "Info"
| where Message startswith_cs "OCSP Response"
| project serial = extract("Serial Number ([A-F0-9]+)", 1, Message)
| distinct serial
| extend serial_start = substring(serial,0,2)
| join kind=leftouter map_certtype on serial_start
| summarize count() by (readable)
